1 Project Statement

The idea for this project was borne out of the frustrations of the author in dealing with a railway commute in Great Britain. More specifically, the question asked was How many trains are cancelled each day in Great Britain?

2 Environment and Libraries

In order to ensure a reproducible environment, this project makes use of renv to manage its dependencies. Once renv has restored the environment the project was created in, the required libraries will be loaded.

# Restore dependencies with renv
if (!require("renv")) {
    install.packages("renv")
}

library(renv)
renv::restore()

# Load required libraries
library(circlize)
library(ComplexHeatmap)
library(cowplot)
library(data.table)
library(dplyr)
library(janitor)
library(lubridate)
library(plyr)
library(purrr)
library(readxl)
library(spiralize)
library(tidyverse)

ComplexHeatmap and spiralize require installation from Github rather than CRAN. If any issues arise during the environment restoration, the following devtools commands can be used to install the libraries:
devtools::install_github(“jokergoo/ComplexHeatmap”)
devtools::install_github(“jokergoo/spiralize”)

3 Data Origins

The data used in this project was obtained from the NWR Historic Delay Attribution data set, licensed under the Open Government Licence v3.0 on the Rail Data Marketplace. It contains all the delay and cancellation data for all railway operators in Great Britain, ranging from, at the time of writing, the 2015-2016 fiscal year up until October 12th 2024 (Rail Delivery Group, 2024).

3.1 Variables

These are the variables included in this project. Not all of them ended up being used in the final visualisation, but have been retained to allow for different types of analyses or graphs in any future adaptations of this project. Refer to the code book for more details on these variables.

Variable	Description
departure_date	The date of the cancellation
event_type	The type of cancellation
react_reason	The reason for the cancellation
toc_code	The train operator
stanox	The numerical code for the point of origin

3.2 Reading the Data

The first step is to read and clean the raw data. At the time this project was completed a total of 124 files covering the time period between April 1st 2015 and October 12th 2024 were used.

# Create a list of train operator codes (TOC) for passenger train operators to
# filter out the relevant observations
tocs <- c("EA", "EB", "EC", "ED", "EE", "EF", "EH", "EJ", "EK", "EM", "ES", "ET",
    "EX", "HA", "HB", "HE", "HF", "HL", "HM", "HO", "HT", "HU", "HX", "HY", "LD",
    "LN", "PF", "XB", "XC", "XE")

# Create a list of column names that need to be renamed
rename_cols = c(toc_code = "operator_affected", event_type = "performance_event_code",
    react_reason = "reactionary_reason_code", stanox = "start_stanox")

# Read file names in the raw data folder
csvfiles <- c(list.files(path = "raw", pattern = "\\.csv$", full.names = TRUE))

# Create a list to populate with data frames
train_frame <- list()

# Use a loop to read the files.
for (i in 1:length(csvfiles)) {

    # Create a csv reader function
    train_reader <- function(filelist) {

        # Read the files using fread
        plyr::ldply(filelist, fread) %>%
            # Convert column names to snake case using janitor
        janitor::clean_names() %>%
            # Rename columns
        dplyr::rename(any_of(rename_cols)) %>%
            # Drop observations that contain delay data and planned
            # cancellations
        filter(event_type != "M" & event_type != "F" & event_type != "A" & event_type !=
            "O" & event_type != "S") %>%
            # Filter by passenger train operators
        filter(toc_code %in% tocs) %>%
            # Convert the date format using lubridate
        mutate(departure_date = parse_date_time(origin_departure_date, c("dmy", "%d/%m/%Y %H%M")),
            .before = origin_departure_date) %>%
            # Change data type to date
        mutate(departure_date = as.Date(departure_date)) %>%
            # Keep only the columns that are of interest
        select(departure_date, toc_code, event_type, react_reason, stanox)
    }

    # Populate the list
    train_frame[[i]] <- train_reader(csvfiles[i])
}

# Reduce the large list to a single data frame using purrr
master_df <- train_frame %>%
    reduce(full_join)

3.3 Sanity Check

Sanity check to see if the data was read correctly.

# Create an assert function for sanity checks
assert <- function(value, target) {
    # This function crashes the code if value does not equal target
    if (value == target) {
        print("Value equals target")
    } else {
        stop("Value does not equal target")
    }
}

# Count number of days between first and last observation
date_diff <- as.numeric(difftime(max(master_df$departure_date), min(master_df$departure_date),
    units = "days"))

# Sanity check
assert(length(unique(master_df$departure_date)), date_diff)

## [1] "Value equals target"

3.4 Descriptors

This section is not strictly necessary for the project, but has been included for transparency and readability. This code will add descriptors for the variables in the data frame and save it as a csv file, which allows for access to the data used in the project without needing to obtain access to the Rail Data Marketplace.

# Create a train operator data frame. This is easier than reading it from the
# glossary as it contains a lot of freight operators
operators <- data.frame(toc_code = c("EA", "EB", "EC", "ED", "EE", "EF", "EH", "EJ",
    "EK", "EM", "ES", "ET", "EX", "HA", "HB", "HE", "HF", "HL", "HM", "HO", "HT",
    "HU", "HX", "HY", "LD", "LN", "PF", "XB", "XC", "XE"), operator = c("TransPennine Express",
    "Greater Anglia", "Grand Central", "Northern", "Heathrow Connect", "Great Western Railway",
    "CrossCountry", "West Midlands Railway", "London Overground", "East Midlands Railway",
    "Caledonian Sleeper", "Govia Thameslink Railway", "Elizabeth line", "ScotRail",
    "LNER", "Merseyrail", "Avanti West Coast", "Transport for Wales", "Heathrow Express",
    "Chiltern Railways", "c2c", "Southeastern", "Thameslink", "South Western Railway",
    "Lumo", "London Northwestern Railway", "Hull Trains", "LUL District Line - Wimbledon",
    "LUL Bakerloo Line", "LUL District Line - Richmond"))

# Merge train operator data frame with the master data frame
master_df <- master_df %>%
    left_join(operators, by = c("toc_code"))

# Read description for cancellation codes
react_codes <- read_excel("data/glossary.xlsx", sheet = "Reactionary Reason Code") %>%
    # Convert column names to snake case
clean_names() %>%
    # Drop the reason name column
select(-3) %>%
    # Rename columns
dplyr::rename(react_reason = reactionary_reasons_reactionary_reason_code)

# Merge cancellation codes data frame with the master data frame
master_df <- master_df %>%
    left_join(react_codes, by = c("react_reason"))

# Read description for event types
event_types <- read_excel("data/glossary.xlsx", sheet = "Performance Event Code") %>%
    # Convert column names to snake case
clean_names() %>%
    # Drop the performance event column
select(-2) %>%
    # Rename columns
dplyr::rename(event_type = performance_event_types_performance_event_code)

# Merge event types data frame with the master data frame
master_df <- master_df %>%
    left_join(event_types, by = c("event_type"))

# Rearrange columns for better readability
master_df <- master_df[, c(1, 3, 8, 4, 7, 2, 6, 5)]

# Save master data frame as a csv file and compress it
write.csv(master_df, file = gzfile("data/masterfile.csv.gz"))

4 Visualisation

Since the data set contains a huge amount of data (3,434,722 observations), deciding how to best present it took some trial and error. After exploring various options, such as line graphs, choropleth maps and heat maps, a spiral plot was chosen. A spiral plot maps time-based data along an Archimedean spiral, which makes it ideal for visualising large data sets over a large time period.

4.1 Count Cancellations

Before creating the plot some preparation is required. Since the objective is to look at cancellations over time, a count of cancellations by departure date is needed. To make sure the number of cancellations is correct, a sanity check will be performed by comparing the total sum with the number of observations in the master data frame.

# Count the number of cancellations by date
train_count <- master_df %>%
    group_by(departure_date) %>%
    tally()

# Sanity check, number of cancellations should equal number of observations in
# master data frame
assert(nrow(master_df), sum(train_count$n))

## [1] "Value equals target"

4.2 Creating a Spiral Plot Function

The next step is creating a function that maps the data along an Archimedean spiral using the spiralize library.

# Create a spiral plot function that requires the input of a data frame and a
# starting and ending date in the format 'YYYY-MM-DD'. Refer to the
# documentation for the spiralize library for further details on its functions
spiral_plot <- function(df, start, end) {

    # Use a temporary data frame to store the filtered date range
    temp_df <- df %>%
        filter(departure_date > start & departure_date < end)

    # Initialize the spiral graph. As the spiral is 360 degrees, the choice is
    # to either normalize each year to 360 or to plot each year as 365/366
    # days. Both options have their drawbacks and advantages
    spiral_initialize_by_time(xlim = range(temp_df$departure_date), verbose = FALSE,
        normalize_year = FALSE)

    # Load data track. The range of the y axis is set to be slightly higher
    # than the maximum value
    spiral_track(height = 0.8, background = FALSE, ylim = c(0, 1.05 * max(temp_df$n)))

    # Draw backgrounds for the breakpoints. TRACK_META reads the meta data of
    # the current track
    bg_col = c("#F8F8F8", "#F0F0F0", "#E8E8E8", "#E0E0E0")
    for (i in 1:4) {
        spiral_rect(TRACK_META$xlim[1], TRACK_META$ylim[1] + TRACK_META$yrange *
            (i - 1)/4, TRACK_META$xlim[2], TRACK_META$ylim[1] + TRACK_META$yrange *
            i/4, gp = gpar(fill = bg_col[i], col = NA))
    }

    # Draw bar plot
    spiral_bars(temp_df$departure_date, temp_df$n, gp = gpar(fill = 4, col = 4))

    # Create unit labels

    # Read the maximum value of the y axis
    max = TRACK_META$ymax
    # Set the start point as 0 and the end point as max
    at = grid.pretty(c(0, max))
    # Create breakpoints between 0 and max
    at = at[at <= max]
    # Place the labels along the y axis
    labels = as.character(at)
    # Add a K label to indicate thousands
    labels[at >= 1000 & at < 1e+06] = paste0(at[at >= 1000 & at < 1e+06]/1000, "K")
    # Draw it at the beginning and end of the spiral
    spiral_yaxis(at = at, labels = labels, labels_gp = gpar(fontsize = 5))

    # Create month and year labels

    # Read the final date in the range
    dd = max(temp_df$departure_date)
    # Set the day to the 15th as a midpoint
    day(dd) = 15
    # Add the months
    dd = dd + months(1:12)
    # Draw the labels
    spiral_text(dd, y = 1.5, month.name[month(dd)], facing = "inside", nice_facing = TRUE)

    # Create a vector with the years in the date range
    years = as.character(unique(year(temp_df$departure_date)))

    for (i in 1:length(years)) {
        # Place a year label on January 1st of each year
        spiral_text(sprintf("%s-01-01", years[i]), TRACK_META$ycenter, years[i],
            gp = gpar(fontsize = 8))
    }

    # Create the title
    grid.text(sprintf("Train cancellations in Great Britain, %s-%s", first(years),
        last(years)), x = unit(0, "npc") + unit(0, "mm"), y = unit(1, "npc") - unit(0,
        "mm"), gp = gpar(fontsize = 14))

    # Add source
    grid.text("Source: NWR Historic Delay Attribution licensed under OGL v3.0.",
        x = unit(0, "npc") + unit(0, "mm"), y = unit(0, "npc") - unit(0, "mm"), gp = gpar(fontsize = 8))
}

4.3 Plotting the Data

Now that the function has been created, plots of any date range within the data frame can easily be drawn. To test it out, a plot of the entire data set is drawn.

# Draw the plot
spiral_plot(train_count, "2015-04-01", "2024-10-12")

Unfortunately, it looks like there is a bit of an information overload going on here, so readability is not great. The drawback of plotting 365/366 day years on a 360 degree spiral can also be seen as the years are drifting and not aligning correctly with the months.

4.4 Improving the Plot

The first idea for improving the plotting was to split it into three plots covering roughly three years each.

# Draw the plots
spiral_plot(train_count, "2015-04-01", "2017-12-31")
spiral_plot(train_count, "2018-01-01", "2020-12-31")
spiral_plot(train_count, "2021-01-01", "2024-10-12")

Better, but still problematic. There is still some drift of the years and there are uneven distributions. The first year label is also obscuring the unit labels on two of the plots.

4.5 Improving the Plot Again

The next idea was to draw each year separately and then put all the plots into a grid. To do this, the plotting function has to be revisited and modified slightly. The most important modification is adding a vector that will hold the maximum y axis value for the entire data set. Without setting this the plots would end up being on different scales, which would make the grid appear visually deceptive as well as making comparisons needlessly difficult. A label that displays the total amount of cancellations per year has also been added.

## Draw a grid of all years
grid_plot <- function(df, start, end) {

    # Store the maximum y axis value for the entire data set
    y_maximum = max(df$n)

    # Use a temporary data frame to store the filtered date range
    temp_df <- train_count %>%
        filter(departure_date > start & departure_date < end)

    # Initialize the spiral graph. As the spiral is 360 degrees, the choice is
    # to either normalize each year to 360 or to plot each year as 365/366
    # days. Both options have their drawbacks and advantages
    spiral_initialize_by_time(xlim = range(temp_df$departure_date), verbose = FALSE,
        normalize_year = FALSE)

    # Load data track. Since each year is now plotted separately, the y max is
    # changed to the maximum for the entire data set
    spiral_track(height = 0.8, background = FALSE, ylim = c(0, 1.05 * max(y_maximum)))

    # Draw backgrounds for the breakpoints. TRACK_META reads the meta data of
    # the current track
    bg_col = c("#F8F8F8", "#F0F0F0", "#E8E8E8", "#E0E0E0")
    for (i in 1:4) {
        spiral_rect(TRACK_META$xlim[1], TRACK_META$ylim[1] + TRACK_META$yrange *
            (i - 1)/4, TRACK_META$xlim[2], TRACK_META$ylim[1] + TRACK_META$yrange *
            i/4, gp = gpar(fill = bg_col[i], col = NA))
    }

    # Draw bar plot
    spiral_bars(temp_df$departure_date, temp_df$n, gp = gpar(fill = 4, col = 4))

    # Create unit labels

    # Read the maximum value of the y axis
    max = TRACK_META$ymax
    # Set the start point as 0 and the end point as max
    at = grid.pretty(c(0, max))
    # Create breakpoints between 0 and max
    at = at[at <= max]
    # Place the labels along the y axis
    labels = as.character(at)
    # Add a K label to indicate thousands
    labels[at >= 1000 & at < 1e+06] = paste0(at[at >= 1000 & at < 1e+06]/1000, "K")
    # Draw it at the beginning and end of the spiral
    spiral_yaxis(at = at, labels = labels, labels_gp = gpar(fontsize = 5))

    # Create month and year labels

    # Read the final date in the range
    dd = max(temp_df$departure_date)
    # Set the day to the 15th as a midpoint
    day(dd) = 15
    # Add the months
    dd = dd + months(1:12)
    # Draw the labels
    spiral_text(dd, y = 1.5, month.name[month(dd)], facing = "inside", nice_facing = TRUE,
        gp = gpar(fontsize = 8))

    # Create a vector with the years in the date range
    years = as.character(unique(year(temp_df$departure_date)))

    # Create the title
    grid.text(sprintf("%s", years), x = unit(0, "npc") + unit(0, "mm"), y = unit(1,
        "npc") - unit(0, "mm"), gp = gpar(fontsize = 14))

    # Add number of cancellations
    grid.text(sprintf("Total cancellations: %s", format(sum(temp_df$n), big.mark = ",")),
        x = unit(0, "npc") + unit(-6, "mm"), y = unit(1, "npc") - unit(5, "mm"),
        just = "left", gp = gpar(fontsize = 8))
}

After modifying the function some vectors need to be defined. These will hold the ranges of dates that will be used to draw a plot of each year.

# Count the number of years and create lists of start and end dates
yrs = as.character(unique(year(train_count$departure_date)))
start = c("2015-04-01", "2016-01-01", "2017-01-01", "2018-01-01", "2019-01-01", "2020-01-01",
    "2021-01-01", "2022-01-01", "2023-01-01", "2024-01-01")
end = c("2015-12-31", "2016-12-31", "2017-12-31", "2018-12-31", "2019-12-31", "2020-12-31",
    "2021-12-31", "2022-12-31", "2023-12-31", "2024-10-12")

Next, these vectors can be fed into a loop that populates a list of plots.

# Create a list to be populated
pl = list()

# Run a loop to populate the list
for (i in 1:length(yrs)) {

    pl[[i]] <- grid.grabExpr({
        grid_plot(train_count, start[i], end[i])
    })
}

Finally, the plots are combined into a grid and have a title and a source attribution added.

# Create the title
title <- ggdraw() + draw_label(sprintf("Train cancellations in Great Britain, %s-%s",
    first(yrs), last(yrs)), fontface = "bold", size = 20, x = 0, hjust = 0) + theme(plot.margin = margin(0,
    0, 0, 7))

# Plot the grid of years
plot_row <- plot_grid(plotlist = pl, ncol = 4)

# Combine title with grid of years
plot_grid(title, plot_row, ncol = 1, rel_heights = c(0.1, 1))

# Add source attribution
grid.text("Source: NWR Historic Delay Attribution licensed under the Open Government Licence v3.0.\nCC-BY-SA Kim Idar Giske",
    x = unit(0.5, "npc") + unit(5, "mm"), y = unit(0.05, "npc") - unit(0, "mm"),
    just = "left", gp = gpar(fontsize = 8))

Grid plot

Click on the figure to see it in a higher resolution.

4.6 Saving the Final Visualisation

The final visualisation is saved as an svg file, which allows for scaling without loss of information.

# Save the grid plot
svg("figs/all_years.svg", width = 20, height = 15)
plot_grid(title, plot_row, ncol = 1, rel_heights = c(0.1, 1))
grid.text("Source: NWR Historic Delay Attribution licensed under the Open Government Licence v3.0.\nCC-BY-SA Kim Idar Giske",
    x = unit(0.5, "npc") + unit(5, "mm"), y = unit(0.05, "npc") - unit(0, "mm"),
    just = "left", gp = gpar(fontsize = 8))
invisible(dev.off())

5 Summary

5.1 Interpretation

The most obvious conclusion one can draw by looking at the data is that the number of cancellations have been steadily increasing over the years. This could be due to any number of reasons, but by looking into some of the highest spikes throughout the years, it seems that extreme weather events are at least partially responsible. Below is a list of some of the most severe spikes and corresponding weather events:

Date	Cancellations	Weather Event
June 23rd, 2016	4749	Severe flooding
February 23rd, 2017	5007	Storm Doris
February 26th-March 3rd, 2018	22,627	Extreme cold spell
September 19th-21st, 2018	5720	Storms Ali and Bronagh
November 26th-27th, 2021	6082	Storm Arwen
February 16th-21st, 2022	25,116	Storms Dudley, Eunice and Franklin
February 16th-21st, 2022	15,005	Extreme heatwave
December 8th-18th, 2022	21,236	Extreme cold spell
January 2nd, 2024	5482	Storm Henk

The weather data in this table is sourced from the UK Storm Centre (Met Office, 2024b) and case studies of past weather events (Met Office, 2024a) on the Met Office website.

5.2 Limitations

Throughout this project, the number one glaring limitation has been the inability to normalise the data. Whilst the Office of Rail and Road has a data set on train cancellations that includes the number of planned trains, it is not as granular as the delay and cancellation data set from the Rail Data Marketplace. Furthermore, it only contains data starting with the 2019-2020 fiscal year, and the data is organised by period rather than by date. Without the possibility to normalise the data, it is impossible to tell whether certain regions or stations are more impacted by cancellations than others.

Another limitation with the data is the fact that just over one third of the cancellations (1,171,651) are coded as “OU - Delays not investigated by Network Rail”. These are cancellations that were not investigated on the date of occurrence and subsequently failed to be investigated within contractual timescales (seven calendar days). Thus, any visualisations on the reasons for cancellations would not be telling the whole story.

5.3 Follow-ups

This data set has a wealth of information and could be visualised in a variety of ways. It could for instance be used to compare the differences in the number of cancellations by train operators or it could be used to plot the number of cancellations by routes or regions. Another follow-up could be to look closer into the correlations between cancellations and weather events and whether the frequency of cancellations caused by weather events is increasing. Can climate change be tracked via train cancellations?

References

Barrett, T., Dowle, M., Srinivasan, A., Gorecki, J., Chirico, M., Hocking, T., & Schwendinger, B. (2024). Data.table: Extension of ‘data.frame‘. https://r-datatable.com

Firke, S. (2023). Janitor: Simple tools for examining and cleaning dirty data. https://github.com/sfirke/janitor

Grolemund, G., & Wickham, H. (2011). Dates and times made easy with lubridate. Journal of Statistical Software, 40(3), 1–25. https://www.jstatsoft.org/v40/i03/

Gu, Z. (2022). Complex heatmap visualization. iMeta. https://doi.org/10.1002/imt2.43

Gu, Z. (2024a). Circlize: Circular visualization. https://github.com/jokergoo/circlize

Gu, Z. (2024b). ComplexHeatmap: Make complex heatmaps. https://github.com/jokergoo/ComplexHeatmap

Gu, Z. (2024c). Spiralize: Visualize data on spirals. https://github.com/jokergoo/spiralize

Gu, Z., Eils, R., & Schlesner, M. (2016). Complex heatmaps reveal patterns and correlations in multidimensional genomic data. Bioinformatics. https://doi.org/10.1093/bioinformatics/btw313

Gu, Z., Gu, L., Eils, R., Schlesner, M., & Brors, B. (2014). Circlize implements and enhances circular visualization in r. Bioinformatics, 30, 2811–2812.

Gu, Z., & Huebschmann, D. (2021). Spiralize: An r package for visualizing data on spirals. Bioinformatics. https://doi.org/10.1093/bioinformatics/btab778

Met Office. (2024a). Past weather events. Met Office. https://www.metoffice.gov.uk/weather/learn-about/past-uk-weather-events

Met Office. (2024b). UK storm centre. Met Office. https://www.metoffice.gov.uk/weather/warnings-and-advice/uk-storm-centre/index

Ooms, J. (2024). Rsvg: Render SVG images into PDF, PNG, (encapsulated) PostScript, or bitmap arrays. https://docs.ropensci.org/rsvg/

R Core Team. (2024). R: A language and environment for statistical computing. R Foundation for Statistical Computing. https://www.R-project.org/

Rail Delivery Group. (2024). NWR historic delay attribution. RSP Limited. https://raildata.org.uk/dashboard/dataProduct/P-3fade1ab-0a85-4ac6-bc51-17c770350af3/dataFiles

Spinu, V., Grolemund, G., & Wickham, H. (2023). Lubridate: Make dealing with dates a little easier. https://lubridate.tidyverse.org

Ushey, K., & Wickham, H. (2024). Renv: Project environments. https://rstudio.github.io/renv/

Wickham, H. (2011). The split-apply-combine strategy for data analysis. Journal of Statistical Software, 40(1), 1–29. https://www.jstatsoft.org/v40/i01/

Wickham, H. (2023a). Plyr: Tools for splitting, applying and combining data. http://had.co.nz/plyr

Wickham, H. (2023b). Tidyverse: Easily install and load the tidyverse. https://tidyverse.tidyverse.org

Wickham, H., Averick, M., Bryan, J., Chang, W., McGowan, L. D., François, R., Grolemund, G., Hayes, A., Henry, L., Hester, J., Kuhn, M., Pedersen, T. L., Miller, E., Bache, S. M., Müller, K., Ooms, J., Robinson, D., Seidel, D. P., Spinu, V., … Yutani, H. (2019). Welcome to the tidyverse. Journal of Open Source Software, 4(43), 1686. https://doi.org/10.21105/joss.01686

Wickham, H., & Bryan, J. (2023). Readxl: Read excel files. https://readxl.tidyverse.org

Wickham, H., François, R., Henry, L., Müller, K., & Vaughan, D. (2023). Dplyr: A grammar of data manipulation. https://dplyr.tidyverse.org

Wickham, H., & Henry, L. (2023). Purrr: Functional programming tools. https://purrr.tidyverse.org/

Wilke, C. O. (2024). Cowplot: Streamlined plot theme and plot annotations for ggplot2. https://wilkelab.org/cowplot/

Xie, Y. (2023). formatR: Format r code automatically. https://github.com/yihui/formatR

PSY 6422 Project

Kim Idar Giske
Registration number: 240196505

2024-11-27

1 Project Statement

2 Environment and Libraries

3 Data Origins

3.1 Variables

3.2 Reading the Data

3.3 Sanity Check

3.4 Descriptors

4 Visualisation

4.1 Count Cancellations

4.2 Creating a Spiral Plot Function

4.3 Plotting the Data

4.4 Improving the Plot

4.5 Improving the Plot Again

4.6 Saving the Final Visualisation

5 Summary

5.1 Interpretation

5.2 Limitations

5.3 Follow-ups

References

PSY 6422 Project

Kim Idar Giske Registration number: 240196505

2024-11-27

1 Project Statement

2 Environment and Libraries

3 Data Origins

3.1 Variables

3.2 Reading the Data

3.3 Sanity Check

3.4 Descriptors

4 Visualisation

4.1 Count Cancellations

4.2 Creating a Spiral Plot Function

4.3 Plotting the Data

4.4 Improving the Plot

4.5 Improving the Plot Again

4.6 Saving the Final Visualisation

5 Summary

5.1 Interpretation

5.2 Limitations

5.3 Follow-ups

References

Kim Idar Giske
Registration number: 240196505
